- New
Hermetic Aluminum Enclosure IP66 IK10 Outdoor Mounting Box Anti-Corrosion Service Cabinet Delta SH-410/310/203
zł544.03
Tax included
The SH-410/310/203 hermetic enclosure is an advanced structural solution designed for the professional protection of electronic and electrical equipment in the most extreme environmental conditions. The use of high-quality PA11 aluminum alloy is the foundation of its reliability. This material is characterized by superior corrosion resistance, which is crucial for installations located in coastal areas with high salinity, or in chemical and industrial plants with aggressive atmospheres. Thanks to the use of aluminum, the enclosure is both lightweight and extremely mechanically durable.
The product offers full protection against external factors thanks to its IP66 certification. This means the interior is completely protected against the ingress of dust and against strong jets of water under pressure. The durable rubber gasket maintains its properties for many years without degrading, ensuring continuous tightness. Another important parameter is the IK10 mechanical resistance class. The enclosure is resistant to vandalism and accidental high-energy impacts, making it an ideal choice for public and unprotected areas.
The interior of the enclosure, with usable dimensions of 390 x 290 x 180 mm, allows for the free arrangement of components such as routers, buffer power supplies, PLC controllers, or recorders. The included metal mounting plate allows for precise and stable attachment of equipment. The bottom part of the body has factory-prepared cable holes, which significantly speeds up the installation process and ensures a tight cable passage when using appropriate cable glands. The light gray (RAL 7035) design is neutral and aesthetic, blending well with building facades. The product is covered by a 2-year warranty, confirming its high quality and the manufacturer's attention to technical details.
Hermetic Aluminum Enclosure IP66 IK10 Outdoor Mounting Box Anti-Corrosion Service Cabinet
Model: Delta SH-410/310/203
EAN: 6931240042717 SKU: 931042714
- Made of high-quality PA11 aluminum
- Full hermetic seal confirmed by IP66 rating
- Maximum mechanical impact resistance IK10
- High corrosion resistance in marine and industrial environments
- Includes a 258 x 358 mm metal mounting plate
- Rubber gasket ensuring long-term tightness
- Factory-made cable entries at the bottom
- Designed for direct wall mounting
- Neutral RAL 7035 color (light gray)
Description
The SH-410/310/203 hermetic enclosure is an advanced structural solution designed for the professional protection of electronic and electrical equipment in the most extreme environmental conditions. The use of high-quality PA11 aluminum alloy is the foundation of its reliability. This material is characterized by superior corrosion resistance, which is crucial for installations located in coastal areas with high salinity, or in chemical and industrial plants with aggressive atmospheres. Thanks to the use of aluminum, the enclosure is both lightweight and extremely mechanically durable.
The product offers full protection against external factors thanks to its IP66 certification. This means the interior is completely protected against the ingress of dust and against strong jets of water under pressure. The durable rubber gasket maintains its properties for many years without degrading, ensuring continuous tightness. Another important parameter is the IK10 mechanical resistance class. The enclosure is resistant to vandalism and accidental high-energy impacts, making it an ideal choice for public and unprotected areas.
The interior of the enclosure, with usable dimensions of 390 x 290 x 180 mm, allows for the free arrangement of components such as routers, buffer power supplies, PLC controllers, or recorders. The included metal mounting plate allows for precise and stable attachment of equipment. The bottom part of the body has factory-prepared cable holes, which significantly speeds up the installation process and ensures a tight cable passage when using appropriate cable glands. The light gray (RAL 7035) design is neutral and aesthetic, blending well with building facades. The product is covered by a 2-year warranty, confirming its high quality and the manufacturer's attention to technical details.
Specification
Standard and certification
Full compliance with IP66 hermetic standards and IK10 mechanical resistance
Main material
Specialized PA11 aluminum characterized by the highest resistance to oxidation and electrochemical corrosion
Surface finish
Powder coating in RAL 7035 (light gray) standard, providing an additional protective layer and aesthetic appearance
Mounting plate
Removable metal plate measuring 258 x 358 mm, designed for convenient component mounting
PA11 material properties
Exceptional resistance in marine conditions and industrial environments; high yield strength and fatigue resistance
Tightness and insulation
Use of a professional perimeter rubber gasket, resistant to UV radiation and extreme temperature fluctuations
Cable management
Bottom cable entry system; configuration: 3 holes with a diameter of 21 mm and 3 holes with a diameter of 16 mm
External overall dimensions
407 x 307 x 203 mm (height x width x depth)
Internal workspace
390 x 290 x 180 mm (usable dimensions after closing the door)
Vandal resistance
IK10 classification - highest degree of protection against external mechanical impacts (20 J energy)
IP protection rating
IP66 - dust-tight and protection against strong water jets from any direction
Mounting type
Wall-mounted, adapted for harsh weather conditions; can be mounted on a pole using optional brackets
Device weight
Net weight is 2.39 kg, which ensures easy installation while maintaining structural rigidity
Target application
Installations for CCTV, intrusion detection systems, building automation, telecommunications, and power engineering
Manufacturer warranty
Warranty protection period of 2 years (24 months)
Contents
1x Hermetic aluminum enclosure
1x Metal mounting plate
1x Set of mounting accessories
1x Set of screws with gaskets
Dimensions, Weight
Product dimensions: 203 x 307 x 407 mm (Depth x Width x Height)
Package dimensions: 210 x 310 x 415 mm (Depth x Width x Height)
Product weight: 2390 g
Weight with packaging: 2886 g
