UPS Uninterruptible Power Supply for monitoring and servers 1000VA 600W AVR voltage stabilization cold start Schuko 2 sockets DA
zł226.32
Tax included
The PFM3350-1000 UPS is an advanced, professional solution designed to ensure power continuity for the most demanding electronic systems. With an apparent power of 1000 VA and an active power of 600 W, the device is perfect as an energy guardian for video surveillance systems, data centers, servers, and advanced workstations. Thanks to the use of approximated sine wave technology at the output, the UPS guarantees safe operation of connected components even in the event of a complete power grid failure.
A key advantage of the PFM3350-1000 model is the built-in automatic voltage regulator (AVR), which continuously corrects input current fluctuations, protecting sensitive equipment from voltage spikes without the need to switch to battery mode. This solution significantly extends the lifespan of the internal 12V/9Ah battery. The device features an extremely short switching time (from 4 to 8 ms), making the transition to emergency power virtually unnoticeable for most operating systems and network devices.
The UPS is equipped with two standard CEE 7/3 (Schuko) sockets, allowing for easy connection of typical plugs without the need for additional adapters. The compact Tower housing and wide operating temperature range (from 0°C to 40°C) allow for flexible installation in rack cabinets (on shelves) or directly at computer workstations. The PFM3350-1000 provides reliable protection for data and equipment against unexpected power grid failures.
UPS Uninterruptible Power Supply for monitoring and servers 1000VA 600W AVR voltage stabilization cold start Schuko 2 sockets
Model: DAHUA PFM3350-1000
EAN: 6931240042526 SKU: 931042527
- High apparent power of 1000 VA and active power of 600 W
- Built-in Automatic Voltage Regulator (AVR)
- Very short switch-over time to battery mode: 4 - 8 ms
- Efficient 12V/9Ah battery ensuring long backup time
- Two standard Schuko (CEE 7/3) output sockets
- Full overload and short-circuit protection
- Battery charging capability even when the device is turned off
- Clear operating status indication via LED diodes and sound
- Compact Tower housing for space saving
- Wide input voltage range from 170V to 280V AC
Description
The PFM3350-1000 UPS is an advanced, professional solution designed to ensure power continuity for the most demanding electronic systems. With an apparent power of 1000 VA and an active power of 600 W, the device is perfect as an energy guardian for video surveillance systems, data centers, servers, and advanced workstations. Thanks to the use of approximated sine wave technology at the output, the UPS guarantees safe operation of connected components even in the event of a complete power grid failure.
A key advantage of the PFM3350-1000 model is the built-in automatic voltage regulator (AVR), which continuously corrects input current fluctuations, protecting sensitive equipment from voltage spikes without the need to switch to battery mode. This solution significantly extends the lifespan of the internal 12V/9Ah battery. The device features an extremely short switching time (from 4 to 8 ms), making the transition to emergency power virtually unnoticeable for most operating systems and network devices.
The UPS is equipped with two standard CEE 7/3 (Schuko) sockets, allowing for easy connection of typical plugs without the need for additional adapters. The compact Tower housing and wide operating temperature range (from 0°C to 40°C) allow for flexible installation in rack cabinets (on shelves) or directly at computer workstations. The PFM3350-1000 provides reliable protection for data and equipment against unexpected power grid failures.
Specification
Active power
600 W - efficiency allowing to power a monitoring set or a high-performance workstation
Apparent power
1000 VA - parameter defining the total current capacity of the device
Output voltage waveform
Approximated sine wave - safe for switching power supplies used in electronics
Input voltage
170 V ... 280 V AC (Alternating current with a frequency of 50/60 Hz)
Output voltage
230 V AC (Stabilized by the AVR circuit)
Output frequency
50 Hz ± 0.1 Hz - high frequency precision in battery mode
Switching time
Typically 4 to 8 ms - ensures continuous operation of most digital devices
Internal battery
1 piece - lead-acid 12V / 9Ah, hermetically sealed, maintenance-free
Charging time
Typically 4 to 6 hours to reach 90% capacity after full discharge
Number of power outputs
2 CEE 7/3 (Schuko) sockets with grounding
Technical protections
Fuse protecting against short circuits, advanced overload protection, intelligent overcharge protection, and protection against excessive battery discharge
Signaling and notifications
Visual indication via LED diodes informing about the operating mode (Mains/Battery/Error) and audible alarm (battery discharge alarm, overload)
Power management
The device has a built-in intelligent power management system that monitors network parameters and automatically activates the AVR regulator in case of voltage drops or surges. The firmware is optimized for maximum cell protection, enabling battery charging in 'Off-mode charging', which means the battery is recharged even when the UPS is not currently powering receivers. The system also controls the power cutoff threshold to prevent irreversible battery damage from deep discharge, which is crucial for maintaining the 3-year lifespan declared by the manufacturer.
Environmental conditions
Operating temperature: 0 °C ... 40 °C, permissible relative ambient humidity: 0 % ... 90 % (non-condensing)
Construction and manufacturer
Housing type: Tower (freestanding), Brand: DAHUA, Warranty: 3 years (36 months)
Contents
1x UPS PFM3350-1000 power supply
1x User manual in Polish
1x Warranty card
Dimensions, Weight
Product dimensions: 279 x 101 x 142 mm (D x W x H)
Package dimensions: 340 x 140 x 220 mm (D x W x H)
Product weight: 4940 g
Weight with packaging: 5181 g
