Outdoor Dual PIR and Microwave Detector 15x15m Motion Sensor IP54 Pet Immune Bosch OD850
zł547.44
Tax included
The Bosch OD850 outdoor dual detector is a professional solution designed for intrusion and hold-up alarm systems that require the highest reliability in harsh environmental conditions. The device offers a wide coverage area of 15 x 15 meters, making it an ideal choice for protecting properties, parking lots, and industrial areas. The main advantage of the sensor is the use of advanced dual technology, combining passive infrared (PIR) with microwave (MW) detection. This combination drastically reduces the occurrence of false alarms, which in outdoor conditions can be caused by rapid temperature changes, wind gusts, or sunlight.
The detector is equipped with intelligent signal processing algorithms, such as Motion Analyzer II and LTD (Linear Travel Distance). The Motion Analyzer II system precisely analyzes the time, amplitude, and direction of movement, which allows for distinguishing a moving human from other disturbances. In turn, LTD technology focuses on linear motion detection, ignoring objects performing oscillatory movements, such as tree branches or hanging advertising banners. The robust mechanical construction and high resistance class ensure that the detector operates stably in a wide temperature range from -35°C to +60°C. Choosing the OD850 model is an investment in safety and peace of mind, eliminating troublesome false alarms of the alarm system while maintaining maximum sensitivity to real threats.
Outdoor Dual PIR and Microwave Detector 15x15m Motion Sensor IP54 Pet Immune
Model: Bosch OD850
EAN: 6931240082621 SKU: 931082629
- Advanced dual technology: PIR + Microwave (10.525 GHz)
- Wide detection area: 15 x 15 meters
- Motion Analyzer II technology to eliminate false alarms
- LTD (Linear Travel Distance) system ignoring movement of branches and signs
- Operation in extreme temperature conditions from -35°C to 60°C
- Two alarm relays: supervised Type A and timed Type C
- Dual tamper protection system
- SELV low-voltage operation mode support
Description
The Bosch OD850 outdoor dual detector is a professional solution designed for intrusion and hold-up alarm systems that require the highest reliability in harsh environmental conditions. The device offers a wide coverage area of 15 x 15 meters, making it an ideal choice for protecting properties, parking lots, and industrial areas. The main advantage of the sensor is the use of advanced dual technology, combining passive infrared (PIR) with microwave (MW) detection. This combination drastically reduces the occurrence of false alarms, which in outdoor conditions can be caused by rapid temperature changes, wind gusts, or sunlight.
The detector is equipped with intelligent signal processing algorithms, such as Motion Analyzer II and LTD (Linear Travel Distance). The Motion Analyzer II system precisely analyzes the time, amplitude, and direction of movement, which allows for distinguishing a moving human from other disturbances. In turn, LTD technology focuses on linear motion detection, ignoring objects performing oscillatory movements, such as tree branches or hanging advertising banners. The robust mechanical construction and high resistance class ensure that the detector operates stably in a wide temperature range from -35°C to +60°C. Choosing the OD850 model is an investment in safety and peace of mind, eliminating troublesome false alarms of the alarm system while maintaining maximum sensitivity to real threats.
Specification
Application
Outdoor and indoor in harsh conditions
Sensor type
Dual: Passive infrared (PIR) and microwave (MW)
Detection area
15 x 15 meters
Microwave frequency
10.525 GHz
Alarm outputs
(NO/C/NC) 28 V DC 0.1 A 10 Ω
Alarm relay type A
Normally closed, supervised alarm contact opened upon alarm trigger
Alarm relay type C
Unsupervised, timed relay sends signal upon alarm trigger, operates according to timer settings
Tamper output
Two NC switches DC 28V 0.1A with 10 Ω protection resistor; Activated upon opening the housing
Housing tamper
Normally closed, contact rating max. 125 mA at 25V DC
Power supply
10 V ... 15 V DC
Current consumption
Active state: 62 mA, Standby state: 22 mA
Operating temperature
-35 °C ... 60 °C
Motion Analyzer II algorithm
Motion Analyzer II is an advanced digital signal processing system for the PIR detector. It repeatedly analyzes the pulse duration, signal amplitude, and its polarity. Thanks to this, the software is able to distinguish with the highest precision the thermal signature of a moving human from background noise, such as sudden lighting changes or air mass flows, which is crucial in outdoor installations.
LTD algorithm
LTD (Linear Travel Distance) technology is responsible for analyzing the microwave signal for linear displacement. The software filters out small-amplitude and oscillatory movements, typical for vegetation moved by the wind. This allows the detector to ignore false signals generated by nature, reacting only to the movement of objects that change their position continuously in the protected area.
Maximum output load
3 W resistive load, 125 mA at 25 V DC
Contents
1x Bosch OD850 dual detector
1x Set of mounting accessories
1x User manual
Dimensions, Weight
Product dimensions: 57 x 83 x 165 mm (D x W x H)
Packaging dimensions: 70 x 85 x 180 mm (D x W x H)
Product weight: 290 g
Weight with packaging: 420 g
