Imou Ranger Dual 2x5MP WiFi Indoor PTZ IP Camera AI Detection Siren LED Light Dual Lens

Model: IMOU IPC-S2XP-10M0WED

EAN: 6931240016121 SKU: 931016124

• Dual lens: 5 MP panoramic and 5 MP PTZ
• Intelligent human and pet detection with Imou SENSE™
• Active deterrence: built-in 110dB siren and LED floodlight
• Smart Color Night Vision - four advanced night modes
• Two-way audio communication (microphone and speaker)
• Automatic tracking of moving objects (Smart Tracking)
• Real-time notifications to mobile devices
• Micro SD card support up to 256GB and IMOU cloud storage
• Wireless connectivity Wi-Fi IEEE 802.11 b/g/n with range up to 50m
• Modern H.265 video compression to save disk space

Description

Introducing the innovative IPC-S2XP-10M0WED IP camera from the Ranger Dual series, which redefines indoor security standards. This unique device combines two optical modules: a fixed focal length panoramic module and a moving PTZ module, allowing for simultaneous wide-angle monitoring and detailed tracking of moving objects. With a total resolution of 10 MP (2x 5 MP), the image is crystal clear, enabling accurate identification of people and details in the monitored room.

Specification

IP monitoring system; no WEB interface; operation via mobile application and cloud only.

A key advantage of the device is the use of the advanced Imou SENSE™ artificial intelligence algorithm. This technology allows for extremely precise differentiation of human and pet silhouettes, which drastically reduces the number of false alerts. The camera not only sees but also actively reacts to threats – a built-in 110 dB siren and an LED spotlight effectively deter intruders. The Smart Color Night Vision function offers four night modes, including a full-color image even in complete darkness, ensuring 24/7 protection.

The device offers complete installation freedom thanks to a Wi-Fi module with a range of up to 50 meters. Two-way audio communication allows you to talk to family members or give voice commands to pets. The system is extremely easy to use thanks to the dedicated IMOU Life application, which allows for remote viewing, managing recordings in the cloud or on a Micro SD card (up to 256GB), and receiving instant alerts on your smartphone. Ranger Dual is a comprehensive solution for those looking for an intelligent, multi-tasking, and reliable monitoring system for their home or office.

Total resolution: 10 MP; Camera 1 (PTZ): 2880 x 1620 px (5 MP); Camera 2 (fixed): 2880 x 1620 px (5 MP); Sensors: 2x 1/3" Progressive Scan CMOS.

Standard and System

Lenses: 2x 3.6 mm; Horizontal field of view: 87° for both modules; Provides wide room coverage while maintaining detail.

Resolution and Sensor

IR illuminator range: 15 m; White light illuminator (LED) range: 15 m; Night modes: Smart Color Night Vision (Color, Black and White, Smart, Off).

Optics and Field of View

Horizontal rotation range: 355°; Vertical rotation range: 0° to 90°; Smart Tracking function.

Night Illumination

Built-in high-sensitivity microphone; Built-in speaker; Supports two-way audio (Talkback); Built-in alarm siren 110 dB/m.

PTZ Mechanics

Compression standards: H.265 / H.264; Transmission speed: 15 fps @ 5 MP; Efficient bandwidth and disk space management.

Audio and Alarms

Ethernet: RJ-45 (10/100 Mbps); Wi-Fi: IEEE 802.11 b/g/n (2.4 GHz); Wi-Fi range: up to 50 m in open space; Internal antenna.

Compression and Video

Memory card slot: Micro SD (TF) card support up to 256GB; Dahua brand cards recommended.

Network Connectivity

Imou SENSE™ algorithm; Object classification: humans, pets; Motion detection; Configurable detection zone; Abnormal sound alarm.

Local Memory

Free IMOU Life application available for Android and iOS platforms; Allows full control of the PTZ camera, live preview from two lenses simultaneously, push notification management, recording schedule configuration, and access to the archive in the cloud or on an SD card. The application offers an intuitive interface, the ability to share the camera with other users, and remote triggering of the siren and spotlight. Supports P2P technology, eliminating the need for a public IP address.

AI Image Analysis

D-ZOOM: 8x digital zoom; Full Color: color night mode; Active LED deterrence; RESET button; IMOU Cloud; Operating schedules.

Mobile Software

Supply voltage: 5V DC / 1.5A; Power adapter included (USB plug); Power consumption: max 5.75 W.

Additional Functions

Operating temperature: -10 °C to 45 °C; Humidity: below 95% RH; Ingress protection: IP66 (protection against dust and strong water jets).

Power Supply and Consumption

Type: Indoor PTZ camera; Color: White; Dimensions: Ø 82 x 115 mm; Can be mounted on a ceiling, wall, or placed on a flat surface.

Environmental Conditions

1x Ranger Dual camera

1x 5V/1.5A Power adapter

1x USB power cable

1x Mounting kit (anchors and screws)

1x Mounting template

1x Quick start guide

Housing and Mounting

Dimensions, Weight

Product dimensions: 82 x 82 x 115 mm (D x W x H)

Package dimensions: 190 x 100 x 100 mm (D x W x H)

Product weight: 240 g

Weight with package: 476 g
