4 Channel Wireless Light Switch 230V Remote Control Relay

Model: ACTii AC1560

EAN: 6931240015605 SKU: 156077670

• Remote control for lighting and 230V devices
• 4 independent channels with power up to 1000W each
• Coded 433MHz radio transmission (1:1 system)
• Large range: up to 20m indoors and 100m outdoors
• Settings memory and correct operation after power failure
• Remote control with dedicated wall mount included

Description

Professional 4-channel wireless 230V radio controller with remote. Allows remote management of lighting, motors, and RTV equipment. Thanks to coded 433MHz transmission, it ensures reliable operation without interference. Each channel supports loads up to 1000W. The set includes an ergonomic remote with a wall mount.

Specification

Number of channels

4

Power supply

230V AC (200 - 245V) 50/60Hz

Output power

4x 1000W

Transmission range

Up to 20m indoors, up to 100m outdoors

Operating frequency

433 MHz (coded)

Remote control power supply

1x 23A 12V battery (included)

Material

ABS, Aluminium

Product dimensions

81 x 44 x 21 mm

Certificates

CE, RoHS

Contents

1x 4-channel switch

1x Remote control

1x Wall mount for remote

1x 23A 12V battery

Dimensions, Weight

Product dimensions: 44 x 81 x 21 mm (D x W x H)

Package dimensions: 120 x 120 x 35 mm (D x W x H)

Product weight: 141 g

Weight with packaging: 169 g

Zum Download

• User Manual
• CE Declaration
• SAFETY COMPLIANCE
