- New
48V 50W DC DC Step up Converter for PoE Switches Power Supply Module for CCTV Monitoring Systems Efficient Stepup ATTE ASUC-50-4
zł142.07
Tax included
The ASUC-50-480-OF converter module is a professional DC/DC step-up device designed for advanced power supply systems in the security industry. The main task of this module is to precisely step up the input voltage from the 10-30V DC range to a stable 48V DC level. This solution is perfectly tailored to the needs of IP monitoring systems, where it is necessary to power PoE switches directly from typical 12V or 24V buffer power supplies. This allows the user to easily integrate devices requiring higher voltage into an existing low-voltage infrastructure without the need to replace the entire power system.
The advantage of the device is its extremely high energy efficiency, reaching up to 93% at full 50W load. This means minimal energy loss in the form of dissipated heat, which translates into longer component life and stable operation of the entire system even in closed enclosures. The module is equipped with a number of protections, including key input reverse polarity protection, which effectively protects the electronics from damage due to potential installation errors. Compact dimensions and a mounting system based on snap-in spacer pins make the installation of the module inside power supply enclosures or control cabinets quick and trouble-free. LED signaling of output voltage presence allows for instant verification of the device's operating status without the need for specialized meters. This is a reliable tool for installers looking for an efficient and safe way to convert voltage in CCTV systems, automation, and wireless networks.
48V 50W DC DC Step up Converter for PoE Switches Power Supply Module for CCTV Monitoring Systems Efficient Stepup
Model: ATTE ASUC-50-480-OF
EAN: 6931240021613 SKU: 931021610
- Voltage step-up from 12V/24V range to stable 48V DC
- Very high energy efficiency at 93%
- Maximum output power up to 50W when powered by 12V
- Integrated input reverse polarity protection
- Optical LED indication of output voltage presence
- Easy installation thanks to included snap-in spacer pins
- Compact Open Frame design ideal for integration
- Dedicated to powering PoE switches in IP monitoring systems
Description
The ASUC-50-480-OF converter module is a professional DC/DC step-up device designed for advanced power supply systems in the security industry. The main task of this module is to precisely step up the input voltage from the 10-30V DC range to a stable 48V DC level. This solution is perfectly tailored to the needs of IP monitoring systems, where it is necessary to power PoE switches directly from typical 12V or 24V buffer power supplies. This allows the user to easily integrate devices requiring higher voltage into an existing low-voltage infrastructure without the need to replace the entire power system.
The advantage of the device is its extremely high energy efficiency, reaching up to 93% at full 50W load. This means minimal energy loss in the form of dissipated heat, which translates into longer component life and stable operation of the entire system even in closed enclosures. The module is equipped with a number of protections, including key input reverse polarity protection, which effectively protects the electronics from damage due to potential installation errors. Compact dimensions and a mounting system based on snap-in spacer pins make the installation of the module inside power supply enclosures or control cabinets quick and trouble-free. LED signaling of output voltage presence allows for instant verification of the device's operating status without the need for specialized meters. This is a reliable tool for installers looking for an efficient and safe way to convert voltage in CCTV systems, automation, and wireless networks.
Specification
Device type
DC/DC Step-up Voltage Converter
Application
PoE switch power supply, IP monitoring systems, industrial automation
Input voltage
10 V ... 30 V DC
Output voltage
48 V DC (stabilized)
Maximum output power
50 W (max) @ 12 V DC
Energy efficiency
93 % @ 12 V / 50 W
Number of power inputs
1
Number of power outputs
1
Electrical protections
Input voltage reverse polarity protection
Optical signaling
LED diode indicating output voltage presence
Mounting method
Snap-in spacer pins (included)
Construction
Open Frame module (without enclosure)
Connectors
Screw terminals for wires
Manufacturer warranty
3 years (36 months)
Software and interface
The ASUC-50-480-OF device is an advanced hardware module that does not require external control software or complex software configuration. The user interface is limited to physical screw terminals and an optical LED indicator. The control logic is embedded in a dedicated switching converter integrated circuit, which continuously monitors current and voltage parameters, ensuring output stabilization at 48V DC regardless of input voltage fluctuations in the 10-30V range. The lack of a digital interface (such as Ethernet or USB) eliminates the risk of operating system crashes, which is crucial in CCTV security systems. The module operates in autonomous mode, reacting immediately to power supply, which guarantees the continuity of connected PoE switches without the need for service intervention or firmware updates.
Contents
1x ASUC-50-480-OF converter module
4x Snap-in spacer pins
Dimensions, Weight
Product dimensions: 20 x 61 x 39 mm (D x W x H)
Package dimensions: 53 x 117 x 85 mm (D x W x H)
Product weight: 20 g
Weight with packaging: 32 g
