Full HD Smart Dual Light Active Deterrence 2Mpx 2.8mm PTZ IR LED Outdoor IP Camera

Model: DAHUA IPC-PT1239H-PV-0280B

EAN: 6931240012802 SKU: 931012803

• Full HD 1080p resolution for high image detail
• Smart Dual Light technology - IR and LED illuminator range up to 30m
• Active Deterrence: built-in alarm siren and flashing light
• Full PTZ rotation control (345° pan, 90° tilt)
• Intelligent IVS analysis: human and vehicle classification, perimeter protection
• Built-in microphone and speaker for two-way voice communication
• H.265+ codec support to save disk space
• IP66 weather resistance
• Power supply via 12V DC or PoE network cable
• Free DMSS mobile application for Android and iOS systems

Description

The 2 Mpx IP camera is a modern solution for outdoor monitoring that combines PTZ rotation functionality with innovative Smart Dual Light technology. Thanks to the use of hybrid lighting, the device can provide a clear, color image even in complete darkness at a distance of up to 30 meters, which significantly facilitates the identification of people and vehicles after dark. The main advantage of this model is the Active Deterrence function, which automatically activates the built-in sound siren and flashing white light when an intruder is detected, effectively discouraging unwanted activities.

Specification

Standard: IP, Resolution: 1920 x 1080 - 1080p, 1280 x 720 - 720p, Sensor: 1/2.8 " CMOS, Transmission speed: 25 fps @ 2Mpx

The device offers smooth horizontal rotation up to 345° and tilt up to 90°, allowing for monitoring of vast areas with a single camera. Support for intelligent IVS image analysis enables precise detection of people and vehicles, minimizing the number of false alarms triggered by animals or vegetation. Thanks to two-way audio communication, the user can not only hear what is happening on-site but also issue voice messages. The solid IP66-rated housing guarantees failure-free operation in harsh weather conditions, from rain to severe frost. Power supply via PoE (Power over Ethernet) simplifies installation, eliminating the need to run separate power cables. It is an ideal choice for homes, businesses, and parking lots looking for an intelligent 24/7 security system.

Lens: 2.8 mm, Viewing angle: 103 °

Standard and Image

IR illuminator range: 30 m, LED illuminator range: 30 m, Smart Dual Light mode: Automatic switching of IR to LED upon object detection

Optics

Rotation range: Pan 0°...345°, Tilt 0°...90°, Rotation speed: up to 37.66 °/s (manual), Presets: 50

Night Illumination

Compression method: Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG

PTZ Rotation Functions

Audio: Built-in microphone and speaker, Two-way audio: Yes, Deterrence function: Siren and flashing white light

Compression and Recording

Functions: Line crossing, intrusion, perimeter protection, human detection, vehicle detection

Audio and Alarms

WDR: 120 dB, Noise reduction: 2D/3D NR, F-DNR: Defog, ROI: Yes, BLC/HLC: Yes, ICR: Automatic infrared filter, Privacy zones: 4

Intelligent IVS Analysis

Connector: RJ-45 (10/100 Base-T), Protocols: ONVIF, RTSP, P2P, Max. number of users: 20

Image Functions

The DMSS (Digital Mobile Surveillance System) mobile software is an advanced platform for managing security systems from mobile devices with Android and iOS. The application offers users an extremely wide range of possibilities, including professional remote real-time image preview from anywhere in the world using cloud technology (P2P). The user can easily manage PTZ camera functions, performing pan or tilt of the lens directly from the phone screen. DMSS supports advanced Push notifications that instantly inform about motion detection or intruder entry, allowing for quick reaction and triggering of active deterrence functions such as a siren or LED lighting. The application also enables two-way voice communication thanks to the built-in speaker and microphone in the camera.

Network Interface

The built-in WEB server allows for full configuration of camera parameters directly from a web browser. It enables setting recording schedules, managing AI functions, configuring the network, and updating firmware without the need for an additional recorder.

DMSS Software

Parameters: PoE (802.3af) or 12V DC / 1A, Power consumption: max 12W

WEB Server

Ingress protection class: IP66, Material: Plastic, Operating temperature: -30 °C ... 55 °C, Surge protection: 2 kV

Power Supply

Color: White-black, Menu language: English, Warranty: 3 years

Housing and Environment

1x PTZ rotation camera, 1x Set of mounting accessories, 1x Quick start guide

Additional Data

Dimensions, Weight

Product dimensions: 127 x 127 x 128 mm (D x W x H)

Package dimensions: 160 x 160 x 160 mm (D x W x H)

Product weight: 410 g

Weight with packaging: 680 g
