Surge protection power strip for 19 inch RACK cabinet 1U 8 sockets 3m cable black automatic fuse ACAR ACAR-S8/FA/RACK
zł191.18
Tax included
A professional surge protection power strip is an essential piece of equipment for any 19-inch RACK telecommunications cabinet. The device is designed to provide maximum protection for connected electronic equipment against the effects of sudden voltage spikes and surges in the power grid. Thanks to the use of an advanced filtering system, the strip effectively protects servers, switches, recorders, and other expensive IT equipment from damage, which significantly increases the stability of the entire system.This model features a compact 1U height design, allowing for optimal use of space inside the cabinet. It is equipped with 8 power sockets with a grounding pin, enabling the powering of extensive hardware infrastructure. An additional advantage is the built-in dual-pole, illuminated switch, which allows for quick and safe disconnection of power from all receivers simultaneously, while indicating the presence of voltage in the sockets. User safety is enhanced by two automatic time-delay fuses that protect both current paths from overload.The strip housing is made of high-quality self-extinguishing plastic, which guarantees durability and fire safety. A long power cable of nearly 3 meters provides great installation flexibility, even in tall server cabinets. By choosing this product, you gain the certainty that your network infrastructure is protected by a proven technical solution that minimizes the risk of costly failures and downtime caused by power supply problems.
Surge protection power strip for 19 inch RACK cabinet 1U 8 sockets 3m cable black automatic fuse
Model: ACAR ACAR-S8/FA/RACK
EAN: 6931240054383 SKU: 931054382
- Designed for mounting in standard 19-inch RACK cabinets
- 1U mounting height for space saving
- 8 power sockets with protective contact (grounding pin)
- Advanced surge protection system with varistor
- Dual automatic time-delay fuse protecting both current paths
- Illuminated dual-pole switch indicating device operation
- High-durability self-extinguishing plastic housing
- Long 2.9-meter power cord for easy connection
- Rated load current up to 10A (total)
- Fast protection system response time of less than 25ns
Description
A professional surge protection power strip is an essential piece of equipment for any 19-inch RACK telecommunications cabinet. The device is designed to provide maximum protection for connected electronic equipment against the effects of sudden voltage spikes and surges in the power grid. Thanks to the use of an advanced filtering system, the strip effectively protects servers, switches, recorders, and other expensive IT equipment from damage, which significantly increases the stability of the entire system.
This model features a compact 1U height design, allowing for optimal use of space inside the cabinet. It is equipped with 8 power sockets with a grounding pin, enabling the powering of extensive hardware infrastructure. An additional advantage is the built-in dual-pole, illuminated switch, which allows for quick and safe disconnection of power from all receivers simultaneously, while indicating the presence of voltage in the sockets. User safety is enhanced by two automatic time-delay fuses that protect both current paths from overload.The strip housing is made of high-quality self-extinguishing plastic, which guarantees durability and fire safety. A long power cable of nearly 3 meters provides great installation flexibility, even in tall server cabinets. By choosing this product, you gain the certainty that your network infrastructure is protected by a proven technical solution that minimizes the risk of costly failures and downtime caused by power supply problems.Specification
Rated voltage
230 V AC / 50 Hz - standard mains voltage maintaining full sinusoidal characteristics.
Rated load current
10 A (total for all sockets) - allows connecting multiple devices with a total power of up to 2300W.
Nominal voltage of the surge protection system
250 V / 50 Hz - optimal protection trigger threshold for equipment stability.
Surge protection level
≤ 1.3 kV (L/N) - guarantees low voltage passed to protected devices during a spike.
Number of power sockets
8 sockets with protective contact 10A/250V - standard type E sockets with grounding.
Automatic fuse
Yes - two automatic time-delay fuses protecting both current paths against overload and short circuit.
Nominal discharge current
2 kA (L/N) - 8/20 µs - capacity to discharge standard current pulses.
Maximum discharge current
6.5 kA (L/N) - 8/20 µs - high resistance to strong atmospheric and grid surges.
Leakage current
< 0.5 mA - minimal power consumption by the protection system in standby mode.
Response time
< 25 ns - instantaneous activation of the protection system to safeguard sensitive electronics.
Switch
Dual-pole, illuminated - cuts off both the phase and neutral wire simultaneously for full safety.
Cable length
2.9 m - flexible power cord terminated with an angled plug.
Housing
RACK 19 inch, 1U height, made of black self-extinguishing plastic.
Selected protection features
Surge Protection - protects against voltage spikes; Automatic fuse - eliminates the need to replace fuse links; Self-extinguishing housing - increases fire safety in the server room.
Warranty
2 years - full manufacturer support regarding device reliability.
Contents
1x RACK power strip
1x User manual
Dimensions, Weight
Product dimensions: 55 x 445 x 54 mm (D x W x H)
Packaging dimensions: 55 x 480 x 100 mm (D x W x H)
Product weight: 610 g
Weight with packaging: 800 g
