- New
Lighting Connector Electrical Terminal Block 1-way 24A 400V Spring Clamp Set of 100 pieces WAGO WAGO-224-101*P100
zł166.79
Tax included
The WAGO 224-101 lighting connector is a professional installation component that revolutionizes the way wires are connected in modern electrical systems. Designed specifically for creating reliable connections between rigid solid conductors and flexible stranded conductors, it is widely used primarily in lighting installation, but also in home and industrial automation. The main advantage of this product is the use of patented spring clamp technology, which eliminates the need for tools when connecting stranded wires and guarantees constant clamping force for decades. As a result, the installation is not only faster but also much safer, as the connection is resistant to loosening caused by vibrations or temperature changes, which is a common problem in traditional screw terminals.
The product is characterized by a compact design, which allows it to be freely placed even in very small installation boxes or LED profiles. The housing made of high-quality polyamide is resistant to high temperatures and has self-extinguishing properties, which increases the fire safety level of the entire installation. The connector supports a wide range of conductor cross-sections: from 1.0 to 2.5 mm² for solid wires and from 0.5 to 2.5 mm² for stranded wires, making it an extremely versatile tool in the hands of every electrician. A high current capacity of 24A and a rated voltage of 400V allow it to be used in most household and commercial power circuits. By choosing original WAGO products, you invest in durability and peace of mind, avoiding costly failures and the need for periodic inspections of electrical connections. The package contains 100 pieces of connectors, which is an optimal supply for professional installation teams.
Lighting Connector Electrical Terminal Block 1-way 24A 400V Spring Clamp Set of 100 pieces
Model: WAGO WAGO-224-101*P100
EAN: 6931240088838 SKU: 931088836
- Enables fast connection of solid conductors with stranded conductors
- CAGE CLAMP spring clamp technology ensuring contact durability
- Tool-free stranded wire installation by pressing the housing
- High current capacity up to 24A at 400V voltage
- Compact dimensions ideal for tight installation spaces
- Housing made of self-extinguishing materials with high thermal resistance
- Set contains 100 pieces of the product in a bulk package
Description
The WAGO 224-101 lighting connector is a professional installation component that revolutionizes the way wires are connected in modern electrical systems. Designed specifically for creating reliable connections between rigid solid conductors and flexible stranded conductors, it is widely used primarily in lighting installation, but also in home and industrial automation. The main advantage of this product is the use of patented spring clamp technology, which eliminates the need for tools when connecting stranded wires and guarantees constant clamping force for decades. As a result, the installation is not only faster but also much safer, as the connection is resistant to loosening caused by vibrations or temperature changes, which is a common problem in traditional screw terminals. The product is characterized by a compact design, which allows it to be freely placed even in very small installation boxes or LED profiles. The housing made of high-quality polyamide is resistant to high temperatures and has self-extinguishing properties, which increases the fire safety level of the entire installation. The connector supports a wide range of conductor cross-sections: from 1.0 to 2.5 mm² for solid wires and from 0.5 to 2.5 mm² for stranded wires, making it an extremely versatile tool in the hands of every electrician. A high current capacity of 24A and a rated voltage of 400V allow it to be used in most household and commercial power circuits. By choosing original WAGO products, you invest in durability and peace of mind, avoiding costly failures and the need for periodic inspections of electrical connections. The package contains 100 pieces of connectors, which is an optimal supply for professional installation teams.
Specification
Connection standard
CAGE CLAMP - innovative WAGO spring clamp system ensuring constant pressure
Number of ways
1 - dedicated to precise connection of single circuit conductors
Connector type
2 x spring clamp - ensures instant installation and removal of wires
Conductor cross-section (Solid)
1.0 mm² ... 2.5 mm² - full support for standard installation wires
Conductor cross-section (Stranded)
0.5 mm² ... 2.5 mm² - ideal for connecting flexible lighting fixture ends
Rated voltage
400 V - high insulation resistance against breakdown in network installations
Rated current
24 A - allows for safe use in circuits with significant load
Color
Grey - standard color scheme facilitating identification in boxes
Contact material
Electrolytic copper, galvanically tinned for corrosion protection
Housing material
Polyamide (PA 6.6) - material with high mechanical and thermal strength
Stripping length
9 mm ... 11 mm - optimal length to ensure full electrical contact
Mounting method
Push-in on the solid wire side, clamp on the stranded wire side (button)
Technical advantages
Gas-tight connection, total resistance to vibrations and mechanical shocks
Application
Lighting installations, chandeliers, wall lamps, HVAC systems, building automation
Certificates and standards
VDE, UL, CSA, CE - full compliance with international safety standards
Contents
100x WAGO-224-101 Electrical Terminal Block
Dimensions, Weight
Product dimensions: 8 x 21 x 16 mm (Depth x Width x Height)
Package dimensions: 60 x 110 x 85 mm (Depth x Width x Height)
Product weight: 2 g
Weight with packaging: 210 g
