- New
Professional LCD voltage and phase sequence tester AC DC voltage tester RCD test buzzer UNI-T UT-18C
zł216.44
Tax included
The UT-18C voltage and phase sequence tester is an advanced measuring tool from UNI-T, designed for professional electricians, installers, and demanding home users. This versatile device allows for precise measurement of alternating current (AC) and direct current (DC) voltages in a wide range from 12V up to 690V. Thanks to built-in automation, the measurement process is extremely intuitive – simply touch the probes to the measurement points, and the device will instantly select the appropriate range and display the result.
The greatest advantage of the UT-18C model is its dual user information system. Results are presented on a clear LCD display while simultaneously indicated by bright LEDs located in the upper part of the housing, allowing for quick reading even in difficult lighting conditions. The device offers a range of functions critical for the safety and diagnostics of electrical installations. It enables continuity testing with an audible signal, DC voltage polarity detection, and, crucially for three-phase systems, phase sequence determination and phase shift measurement.
Work safety is enhanced by the Residual Current Device (RCD) test function, which allows for controlled tripping of the protection to verify its functionality. Additionally, the tester is equipped with an integrated LED flashlight, making it indispensable when working in switchboards and poorly lit rooms. The robust housing with an ergonomic shape ensures a secure grip and resistance to mechanical damage, which translates into a long service life for the instrument even with intensive use in construction conditions.
Professional LCD voltage and phase sequence tester AC DC voltage tester RCD test buzzer
Model: UNI-T UT-18C
EAN: 6931240081501 SKU: 931081505
- Automatic AC/DC voltage measurement in the range of 12V - 690V
- Clear LCD display and LED indicators
- Phase sequence test in three-phase installations
- Residual Current Device (RCD) test
- Audible and visual continuity signaling
- Built-in LED flashlight for illuminating measurement points
- Voltage tester function (detection above 100V with a single probe)
- Automatic measurement range selection
- Low battery indicator
- Robust housing resistant to workshop conditions
Description
The UT-18C voltage and phase sequence tester is an advanced measuring tool from UNI-T, designed for professional electricians, installers, and demanding home users. This versatile device allows for precise measurement of alternating current (AC) and direct current (DC) voltages in a wide range from 12V up to 690V. Thanks to built-in automation, the measurement process is extremely intuitive – simply touch the probes to the measurement points, and the device will instantly select the appropriate range and display the result.
The greatest advantage of the UT-18C model is its dual user information system. Results are presented on a clear LCD display while simultaneously indicated by bright LEDs located in the upper part of the housing, allowing for quick reading even in difficult lighting conditions. The device offers a range of functions critical for the safety and diagnostics of electrical installations. It enables continuity testing with an audible signal, DC voltage polarity detection, and, crucially for three-phase systems, phase sequence determination and phase shift measurement.
Work safety is enhanced by the Residual Current Device (RCD) test function, which allows for controlled tripping of the protection to verify its functionality. Additionally, the tester is equipped with an integrated LED flashlight, making it indispensable when working in switchboards and poorly lit rooms. The robust housing with an ergonomic shape ensures a secure grip and resistance to mechanical damage, which translates into a long service life for the instrument even with intensive use in construction conditions.
Specification
Main display
High-contrast digital LCD display, presenting current voltage values and technical parameters during measurement.
DC voltage measurement (thresholds)
Seven-level overview measurement and precise LCD reading for voltages: 12V, 24V, 50V, 120V, 230V, 400V, 690V.
AC voltage measurement (thresholds)
Seven-level overview measurement and precise LCD reading for AC voltages: 12V, 24V, 50V, 120V, 230V, 400V, 690V.
Phase sequence detection
Fully integrated phase detection system in the voltage range from 100V to 690V at a mains frequency of 50Hz/60Hz.
Polarity detection
Automatic detection of direct current (DC) polarity with indication of positive and negative poles.
Continuity test
Resistance measurement in the range from 0 to 100 kΩ with simultaneous audible (buzzer) and visual (LED) signaling.
Frequency measurement
Ability to monitor input voltage frequency in a wide range from 40 Hz to 400 Hz.
RCD test
Dedicated function for testing residual current devices in the operating voltage range of approx. 230V (50-400Hz).
Overvoltage indicator
User warning system for the presence of hazardous voltage (above safe standards) using a dedicated LED.
Voltage tester function
Single-pole phase detection mode using the main probe (contact), active at voltages above 100V AC.
Auxiliary lighting
Built-in white LED flashlight, enabling safe work in total darkness or control cabinets.
Device power supply
Device powered by two 1.5V AAA (LR03) batteries, which are included in the factory set.
Dimensions and weight
Compact design with dimensions of 272 x 85 x 31 mm and a weight of only 270g, ensuring high mobility.
Design and ergonomics
Housing made of high-quality plastic, resistant to dirt, with ergonomic ribbing to facilitate grip while wearing gloves.
Contents
1x UT-18C voltage tester
2x 1.5V AAA battery
1x Original blister packaging
1x User manual in Polish
Dimensions, Weight
Product dimensions: 31 x 85 x 272 mm (D x W x H)
Packaging dimensions: 50 x 170 x 355 mm (D x W x H)
Product weight: 270 g
Weight with packaging: 424 g
