Mifare 13.56MHz RFID Proximity Reader RS-485 Wiegand Outdoor IP66 Slim Access Control DAHUA ASR2200A
zł366.54
Tax included
A professional outdoor proximity reader designed by a renowned brand, dedicated to advanced access control systems. The device features a modern, slim design that perfectly blends with contemporary architecture and allows for installation in space-constrained areas, such as door frames.
One of the key advantages of the device is the tempered glass front panel, which not only gives it an elegant appearance but also provides exceptional durability and resistance to scratches and environmental factors. The reader supports the 13.56 MHz Mifare S50 standard, which guarantees a high level of security and reading stability.
Thanks to support for RS-485 and Wiegand communication protocols, the reader is fully universal and can work with a wide range of access controllers available on the market. The robust construction with an IP66 ingress protection rating (after proper sealing during installation) enables trouble-free outdoor operation, even in extreme temperatures from -30°C to 70°C.
System security is enhanced by additional features such as a built-in watchdog, which monitors software operation continuity, and an anti-tamper output, which notifies the system of unauthorized opening or detachment attempts. Clear optical LED signaling and a built-in buzzer provide the user with intuitive feedback on access status. By choosing this model, you invest in reliability, modern aesthetics, and the highest standard of protection for your facility.
Mifare 13.56MHz RFID Proximity Reader RS-485 Wiegand Outdoor IP66 Slim Access Control
Model: DAHUA ASR2200A
EAN: 6931240014936 SKU: 931014934
- Supports 13.56 MHz Mifare card standard (S50)
- Read range up to 5 cm for rapid identification
- Dual communication protocol: RS-485 and Wiegand
- Elegant housing made of tempered glass and durable plastic
- High resistance to atmospheric conditions - IP66 rating
- Integrated Watchdog mechanism to prevent device freezing
- Anti-tamper protection detecting unauthorized device manipulation
- Visual signaling via LED diodes and acoustic signaling (Buzzer)
- Slim design ideal for mounting on posts and narrow profiles
- Wide operating temperature range from -30°C to +70°C
Description
A professional outdoor proximity reader designed by a renowned brand, dedicated to advanced access control systems. The device features a modern, slim design that perfectly blends with contemporary architecture and allows for installation in space-constrained areas, such as door frames.
One of the key advantages of the device is the tempered glass front panel, which not only gives it an elegant appearance but also provides exceptional durability and resistance to scratches and environmental factors. The reader supports the 13.56 MHz Mifare S50 standard, which guarantees a high level of security and reading stability.
Thanks to support for RS-485 and Wiegand communication protocols, the reader is fully universal and can work with a wide range of access controllers available on the market. The robust construction with an IP66 ingress protection rating (after proper sealing during installation) enables trouble-free outdoor operation, even in extreme temperatures from -30°C to 70°C.
System security is enhanced by additional features such as a built-in watchdog, which monitors software operation continuity, and an anti-tamper output, which notifies the system of unauthorized opening or detachment attempts. Clear optical LED signaling and a built-in buzzer provide the user with intuitive feedback on access status. By choosing this model, you invest in reliability, modern aesthetics, and the highest standard of protection for your facility.
Specification
Identification standard
RFID Mifare 13.56 MHz S50
Read range
0 ... 5 cm (depending on ambient conditions and card type)
Communication interface
RS-485 (industrial interference resistant), Wiegand (universal access control standard)
Status signaling
Multicolor LED indicators for status, valid read, or error; Buzzer (acoustic signaling)
Security
Built-in Watchdog (automatic processor reset circuit); Tamper (housing opening and wall detachment sensor)
Device type
Passive reader (requires external access controller)
Keypad
None (version without numeric keypad)
Power supply
12 V DC (± 10%) - direct current from stabilized power supply
Power consumption
Maximum 500 mA (0.5A)
Ingress protection class
IP66 - protection against dust and strong water jets (sealing the contact with the surface with silicone is recommended)
Housing design
PC plastic + tempered glass front panel; Black color with silver finishing elements
Operating conditions
Temperature: -30 °C ... 70 °C; Relative humidity: 5 % ... 95 % (non-condensing)
Mounting method
Surface mount, vertical
Physical dimensions
135 x 40 x 15 mm (height x width x depth)
Contents
1x Proximity reader
1x Set of mounting plugs and screws
1x Quick installation and operation manual
Dimensions, Weight
Product dimensions: 15 x 40 x 135 mm (Depth x Width x Height)
Package dimensions: 55 x 75 x 200 mm (Depth x Width x Height)
Product weight: 110 g
Weight with packaging: 176 g
