2-Channel Wireless Light Switch 230V with Remote Control

Model: ACTii AC9114

EAN: 6931240091142 SKU: 911483759

• Wireless switch
• Remote control included
• Two channels
• 230V power supply
• Robust construction
• Wall mount for remote
• Sleep function - delayed switch-off by approximately 18s

Description

Pressing the corresponding button on the remote sends a signal to the switch, which toggles the selected channel.

ON and OFF buttons turn all channels on or off.

Application: Switching lamps, TVs, motors, fans, video and audio signals, electric door control, locks, windows, etc.

The included holder allows you to mount the remote in a convenient, accessible place.

Two-channel wireless remote relay

Sleep function - delayed switch-off by approximately 18s

Specification

Parameters

Number of channels: 2

Power supply - 230V (200 - 245V) AC 50/60Hz

Output: 2x 1000W

Transmission range: up to 20m indoors, up to 100m outdoors

Wireless transmission frequency: 433MHz

Sleep function - delayed switch-off by approximately 18s

Remote control: YES

Battery in remote - 1 x 23A 12V

Material: ABS, Aluminum

Remote dimensions: 103x45x17mm

Depending on the delivery, the manufacturer's logo may be engraved on the remote

Other information

Batteries for the remote are available in our offer: 23A, 12V battery

Additional information

Connection description:

Black - N (Neutral 230V wire for the switched device, usually blue in a 230V electrical installation)

Black - N (Neutral 230V wire for the switch, usually blue in a 230V electrical installation)

Red - L (Live 230V wire for the switch, usually brown in a 230V electrical installation)

----------

Blue - L (Live 230V wire for the switched device, usually brown in a 230V electrical installation)

White - L (Live 230V wire for the switched device, usually brown in a 230V electrical installation)

--------------

Transmission is encrypted (like a garage door remote). The remote is assigned to the switch and no other remote will operate it.

You can use any number of switches in one location and they will not interfere with each other.

The remote and switch work correctly together immediately and after power loss.

Package contents

Switch

Remote control

Holder

Certificates and standards

CE

ROHS

Dimensions, Weight

Product dimensions: 81 x 44 x 21 mm (Depth x Width x Height)

Package dimensions: 150 x 125 x 30 mm (Depth x Width x Height)

Product weight: 125 g

Weight with packaging: 149 g
