1 Purpose and Features
The set of two professional wall and ceiling mounts ACTii AC9397 has been designed for safe and aesthetic mounting of speakers and home cinema satellite systems. Thanks to the improved joint design, the mounts eliminate the common problem of speakers sagging under their own weight – once the locking screw is tightened, the speaker remains stable in the chosen position. The product allows for the mounting of speakers equipped with a standard 1/4 inch mounting hole, offering full freedom in directing sound in the room.
Main features:
- ✔ The set includes 2 mounts allowing the installation of a pair of speakers.
- ✔ Improved locking mechanism preventing the speaker from moving or sagging after positioning.
- ✔ Construction made of durable aluminium and steel, ensuring durability for years.
- ✔ Full 360° rotation range and ability to tilt sideways by more than 90°.
- ✔ High load capacity of up to 4 kg per individual mount.
- ✔ Universal mounting system compatible with a wide range of popular audio brands.
- ✔ Aesthetic white finish that blends perfectly with light-colored walls and ceilings.
2 Technical Specification
| Model | ACTii AC9397 |
| Material | Aluminium, Steel |
| Color | White |
| Maximum load | 4 kg per mount |
| Rotation adjustment | 360° |
| Tilt adjustment | > 90° |
| Total height | 63 mm |
| Base diameter | 46 mm |
| Speaker mounting screw | 6.35 mm (1/4 "-20) |
| Product dimensions | 48 x 48 x 63 mm |
| Product weight | 67 g |
| Certificates | CE, RoHS |
3 Compatibility
The mounts are compatible with a wide range of satellite speakers equipped with a 1/4 inch mounting thread. Below is a list of example models and manufacturers:
- Logitech: Z103, Z906, Z55
- Pioneer: HTP-071
- Samsung: HT-E4500
- Sony: BDV-N590
- Yamaha: NS-P110, MSP3, NS-P60
- Philips: HTS3541/12
- Bose: Companion, Acoustimass
- Canton: Movie 70, 130, 160, Plus MX.3
- JBL: Control One
- Other brands: Harman Kardon, Teufel, LG, Panasonic, Auna, Heco
4 Installation Manual
Step 1: Surface preparation
Select the mounting location on the wall or ceiling. Make sure there are no electrical wires or water pipes in the chosen spot. Place the mount base (diameter 46 mm) and mark the drilling points.
Step 2: Securing the base
Drill the holes and place the included wall plugs in them. Fasten the mount base using the mounting screws.
Step 3: Speaker installation
Screw the mount's mounting screw (1/4") into the hole located at the back or bottom of the speaker. Tighten the speaker so it adheres stably to the mount head.
Step 4: Adjustment and locking
Loosen the swivel joint, set the speaker to the desired angle (360° rotation and tilt >90° possible). Once the optimal setting is achieved, firmly tighten the mechanism locking screw. Check the stability of the connection.
5 Safety Instructions
- 1. Do not exceed the maximum load of 4 kg per mount. Overloading may lead to damage to the mount or the speaker falling.
- 2. The mounts should be installed only on stable surfaces (concrete, brick, solid wood). For drywall installation, use specialized "molly" type anchors (not included).
- 3. Periodically (once every 6 months) check that the mounting screws and the swivel joint locking mechanism are tight.
- 4. The product is intended for indoor use. Do not expose to direct moisture.
- 5. During ceiling mounting, exercise special caution and ensure that the speaker is screwed in to the full depth of the mounting screw thread.
6 Kit Contents
- 2x ACTii AC9397 wall/ceiling mount
- 2x Set of wall plugs
- 2x Wall mounting screws
- Integrated speaker mounting screws (1/4")
